VALVES stainless steel custom & oe replacements

Dynoman Performance Stainless ValvesDP and KPMI valves are one-piece forgings made from a stainless steel material known as EV8. This is a heavy-duty, high performance material that many companies will use only for exhaust valves because it is so expensive. They then will use a lesser grade of stainless material for the intake valves. We use the EV8 because we believe it is better to use the best possible material for the exhaust and the intake valves.... more >>



KPMI
   HONDA - CB500/550 | CB750 SOHC | CB750 F2 | CB750 DOHC | CB900/1100 DOHC

   KAWASAKI - KZ900/1000 | 1000J/GPz

   SUZUKI - GS1100



Valve Anatomy
Anatomy of a Valve

   Honda -----
CB750 SOHC
CB750 SOHC 1969-76 K & F   |   CB750 SOHC 1977 K
KPMI
KPMI BLACK DIAMOND VALVES
KPMI Valves
   For 1969-76 CB750 F&K* and
   1977 CB750 K
   EV-8 Stainless
   32mm or 33.5mm Intake
   28mm Exhaust

   DP Price $36.95 each in sets of (4)

For F2, please see below
CB750 F2 1977-78 >>

Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals



*1978 K models must use keepers and retainers
from 1969-77 engines

** Running oversized intake valves will require cylinder head modification.

32mm IN
#30-4186
Set of (4) Intake Valves
Standard Size 32mm

$36.95
each valve + shipping

33.5mm IN
#30-4187
Limited availability,
now discontinued.
Set of (4) Intake Valves
Oversized 33.5mm
$49.95 each valve + shipping

28mm EX
#30-4188
Set of (4) Exhaust Valves
Standard Size 28mm
$36.95 each valve + shipping



Single KPMI Valve for CB750SOHC, please specify intake or exhaust and size during check-out
$49.95
for one valve
+ shipping



Vesrah Valves at Dynoman
VESRAH VALVES
Vesrah Valves
   original equipment replacement for
   1969-76 CB750 F/K*

   and 1977 CB750K
   32mm Intake
   28mm Exhaust
   Sold in sets of (8),
   $209.95

*1978 models will require 1969-76 keepers & retainers

For F2, please see below
CB750 F2 1977-78 >>


Set of (8) In & Ex Valves
standard sizes
$209.95 + shipping

HONDA 750 DOHC
CB750 F/K/C  1979-82

Kibblewhite Black Diamond Stainless Steel Valves
for CB750 DOHC and Honda CBX

$27.50 each in sets of (8)

• F.E.A. Designed 1Pc. Lightweight S.S. Forgings
• Increased Resistance to Corrosion
• Excellent Flow Characteristics
• Black Nitride Coated
• 100% Quality Controlled
In order to provide complete coverage of the vintage Honda® DOHC line-up, we are proud to announce the CB750 / CBX Black Diamond™ Stainless Steel Intake and Exhaust Valves. These valves are an OEM upgrade that combine vintage style with the modern design attributes that define our standards here at KPMI®. Our Black Diamond™ Valves have been proven to outlast OEM and provide the performance you desire in your motorcycle.



Set of (8) KPMI INTAKE Valves
#30-4221
$27.50 each = $220.00


Set of (8) KPMI EXHAUST Valves
#30-4222
$27.50 each = $220.00












Vesrah Valves at Dynoman
VESRAH VALVES FOR CB750 F/K/C  DOHC
  1979-82
   Original equipment replacement, oe size,
   excellent price point!

   Limited availability, please email us before ordering!
   Sold in complete set only
   (8) Intake and (8) Exhaust
   $312.00 set of (16)




Set of (8) Intake and (8) Exhaust Valves,
standard size,
for CB750 DOHC engines
$312.00 + shipping
HONDA  900 ~ 1000 ~ 1100   DOHC
CB900F 1981-82 | CB900C 1980-82 | CB1000 1983 | CB1100F 1983

Dynoman Performance
DYNOMAN BLACK DIAMOND VALVES
Dynoman Valves for CB1100F



   +1mm Intakes available now!

   Fits:
   81-82 CB900F & C
   1982 CB1000C
   1983 CB1100F


Dynoman Valves for CB1100FWhy Ours
Are The BEST!

Nitride Coated (B) for super long life, reduced friction, and minimal wear over the life of the valve. One-piece EV8 Stainless Steel material Made in the USA. Designed for maximum FLOW and REDUCED WEIGHT using our exclusive FLOW CUT (A) design. Lighter weight than OE valves! Our valves are more resistant to corrosion and last longer than hard chrome or nickel plated valves.
Very limited availability!

Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals





ORDER HERE


Vesrah Valves at Dynoman
VESRAH VALVES FOR CB900F&C/1000C/CB1100F

   original equipment replacement, oe size, excellent price point!
   Sold in complete set of (8) Intake and (8) Exhaust
   $340.00

* These valves are now discontinued by Vesrah.
Please contact us for availability before ordering!




Set of (8) Intake and (8) Exhaust Valves,
standard size,
for CB900/1000/1100F
$340.00 + shipping

CB750 F2
1977-78 CB750 F2/F3 SOHC

Dynoman Performance
CB750 F2   VALVES

    34mm Intake and 31mm Exhaust


Dynoman Stainless Valves for CB750 F2
WHY OURS ARE BEST
BLACK DIAMOND 1-piece Stainless Steel, Nitride coated and Stellite® tipped for better wear properties and reduced friction. Designed for maximum flow, longer life and maximum resistantance to corrosion, far surpassing hard chrome or nickel plated valves.



Made in the USA for Dynoman by Kibblewhite.

Also available for the F2:
Titanium Retainers | Webcam Cams | Valve Springs | Piston Kits

Stellite® is a cobalt-chromium alloy designed for maximum wear resistance. It also may contain molybdenum and a small amount of carbon. Dynoman F2 valves are the only black Nitride coated available!

Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals




$240.00 set of (8)
CB550/4  & CB500/4
1972 thru 1978
KPMI
KPMI VALVES

Available in standard size 27.5mm/23mm and,  +1 oversize 28.5mm/24mm Black Diamond with Black Nitroneg Stems.
Titanium Retainers also available!


Retail $54.00 each
$46.95 each in set of (4)


Also available for the CB500/CB550:
Web Cams|DP Cams|Valve Springs|Piston Kits|Engine Packages|more


NOTE: When installing oversize intake and exhaust valves in the same head it is important to check for valve to valve intersection. It is sometimes necessary to sink the valves in the head to achieve the proper clearance. It is the responsibility of the engine builder to check all clearances before start up.

Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals, Titanium Retainers, Valve Springs









Set of (4) Intake Valves 27.5mm
$46.95 each valve + shipping

Set of (4) Intake Valves 28.5mm
$46.95 each valve + shipping

Set of (4) Exhaust Valves 23mm
$46.95 each valve + shipping

Set of (4) Exhaust Valves 24mm
$46.95 each valve + shipping

   Kawasaki -----
KZ 900 & 1000
KZ900 / Z-1 1973-77 |
KZ1000 1977-80

KPMI
Performance Valves by

KIBBLEWHITE PRECISION MACHINE
(KPMI)

Fully CNC machined
White Diamond™ Valves are made from a one-pieceKibblewhite White Diamond Valves at Dynoman forging of either EV8 Stainless Steel or Inconel-751. These materials have proven heat and corrosion resistance properties. Each valve is designed using Finite Element Analysis software, and profiles are tested on our computerized flow bench. Strict attention is paid to the surface preparation of the valves, and the purity of the chrome is closely monitored. A 360° anode is used to produce the highest possible grade of hard chrome finish. White Diamond™ Valves are light, strong, one piece forgings with profiles that provide excellent flow characteristics.

All KPMI
Black Diamond Stainless Steel Valves are impregnated by aKibblewhite Valves at Dynoman special German process to .002" deep with a .0002" surface build-up to improve wear properties and reduce friction. This process provides resistance to corrosion and wear that is superior to that developed by hard chromium and electrolysis nickel plating. These valves are light and the profiles provide excellent flow characteristics.

DP PRICE   $29.95 to $34.99 each

* Must use radius groove keepers
  with this valve if your engine came with
  square groove keepers. Available below.



KPMI Valve Keepers at Dynoman
Radius Groove Keepers



Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals





KPMI Valves at Dynoman












Set of (4) Intake Valves
White Diamond #40-4180H
Standard 36mm
$139.96 set of (4)


Set of (4) Intake Valves
White Diamond #40-4181H
Oversize 37.5mm
$139.96 set of (4)

Set of (4) Intake Valves
Black Diamond #40-4182
+6mm Oversized, 42mm
$119.80

limited supply


Set of (4) Exhaust Valves
White Diamond #40-4183H
Standard 30mmm
$139.96 set of (4)


Set of (4) Exhaust Valves
White Diamond #40-4184H
Oversize 31mm
$139.96 set of (4)

Set of (4) Exhaust Valves
Black Diamond 40-4185
+2mm Oversized, 32mm
$119.80 set of (4)

KPMI Radius Groove Keepers
Please contact us for availability
















1000J & GPz
KZ1000 J 1981-82
GPz1100 1981-82


KPMI
KPMI WHITE DIAMOND VALVES:

   Hard chrome stems
   38.5mm Oversize Intakes
   32mm Standard Exhausts
   Set of (4) for $29.95 each



Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals




Set of (4) Intake Valves
Oversize 38.5mm
$27.95 each valve + shipping


Set of (4) Exhaust Valves
Standard 32mm
$27.95 each valve + shipping

   Suzuki -----
GS1100
GS1100 E/ES 1981-83

KPMI
KPMI BLACK DIAMOND VALVES
   Black Nitroneg Stems
   Sizes as shown at right
   Sold in sets of (8)

Please email us to order single valves







Viton Valve Guide Seals at Dynoman

 VITON® Valve Guide Seals









#60-4299
27.5mm Intake Valves (standard tulip) are discontinued


27.5 INTAKE
#60-60220
27.5mm Intake Valve
27° Tulip
Retail $40.14 ea
DP Price $33.95 ea
Sold in set of (8)


28.5 INTAKE
#60-4301
28.5mm Intake Valve
23° Tulip
Retail $40.14 ea
DP Price $33.95 ea
Sold in set of (8)


29.5 INTAKE
#60-4311
29.5mm Intake Valve
23° Tulip
Retail $40.14 ea
DP Price $33.95 ea
Sold in set of (8)


31 INTAKE
#60-4302
31mm Intake Valve
23° Tulip

DP Price $74.95 ea
Sold in set of (8)

24.5 EXHAUST
#60-4304
24.5mm Exhaust Valve
27° Tulip
Retail $40 ea
DP Price $33.95 ea
Sold in set of (8)



cont.....
KPMI also offers an Inconel exhaust valve (1 pc. forging) for blown and fuel engines and Tensilite valves which are 1 pc. titanium forgings.

The KPMI Black Diamond valve is a valve that has undergone a proprietary multi-stage heat-treatment and surface finish process. This treatment actually reacts with the parent material to create a specific hardness to a depth of .002" while maintaining straightness. Once the desired hardness and surface finish are achieved, the valve undergoes a final treatment, which helps prevent galling. These processes, combined with the high-quality EV8 material have combined to create a valve that is strong and virtually impervious to stem wear.
